Galvanized Wire Pipeline Reinforced Mesh HFRM-T Eight Line
Pipeline reinforced Mesh Description:
Pipeline reinforced mesh also known as concrete weight coating mesh, Offshore pipeline counterweight welded wire mesh is a welded mesh commonly used for the reinforcement of concrete-coated pipelines.Pipeline reinforced mesh is a popular product in the global industry, used for concrete-coated offshore oil and gas pipelines. Pipeline reinforced mesh is suitable for both compression and impact coating processes. The wires are deeply crimped to facilitate concrete coating application. The material used is galvanized mild steel. It can be cold-dip galvanized or hot-dip galvanized, deeply crimped to facilitate concrete application.
Pipeline reinforced mesh is available in three sizes: traditional 10-wire, 8-wire, or 6-wire mesh systems. Pipeline reinforced mesh is primarily used for concrete-coated submarine pipelines. In addition to standard sizes, we also offer other sizes that can be customized to meet customer requirements.
Pipeline reinforced Mesh Specifications:
| Product Name | Galvanized Wire Pipeline reinforced mesh HFRM-T Eight Line |
| Material | cold or hot dipped galvanized |
| Type | HFRM-N,HFRM-T,HFRM-L,HFRM-W |
| Wire diameter | 1.6mm-2.85mm |
| Hole size | 25.4mmx67mm or special custom |
| Hardness range | 485N/mm2-650N/mm2 |
| Width per roll | 190.5mm or custom |
| Length per roll | 140m,280m or custom |
| Roll Diameter | 700mm-1000mm |
| Surface | Smooth, bright and clean |
| Use life | Above 20 years |
Normal Export Specifications Kinds:
| Wire Diameter | Mesh | Width | Length |
| 2.0mm/2.0mm | 25.4mmx67mm | 190.5mm | 140m,280m |
| 2.0mm/2.2mm | 25.4mmx67mm | 190.5mm | 140m,280m |
| 2.0mm/2.4mm | 25.4mmx67mm | 190.5mm | 140m,280m |
| 2.0mm/2.7mm | 25.4mmx67mm | 190.5mm | 140m,280m |
| Products can be customized according to customers’ requirements. |
Pipeline reinforced Mesh Features:
The complex submarine environment makes oil pipelines susceptible to seawater impact, corrosion, and collisions with large fish and other animals. A pipeline rupture can cause oil leaks, resulting in not only economic losses but also marine pollution and ecological imbalance. Therefore, oil pipelines require a robust protective structure, leading to the development of submarine oil pipeline nets. Their primary purpose is to wrap around oil pipelines to provide impact and corrosion protection. This product offers strong resistance to tension, collision, and impact.
This product has a neat, regular, and shiny appearance. The net is tightly bundled and securely fastened. The welds are secure, making it easy to transport and stack.
The oil pipeline net undergoes a comprehensive quality inspection before shipment, and third-party inspection reports are available upon request.
Pipeline Reinforced Mesh Applications:
This mesh is first hot-dip galvanized before processing and is mainly used for cement counterweight layers in submarine oil and gas pipelines. Wrapped on the oil pipeline, it plays a role in anti-collision and anti-corrosion protection. It is the preferred product for protecting oil pipelines.
Our company profile:
Our company has 6 sets of the world's most advanced complete wire mesh welding production lines, with an annual production capacity of more than 5 million square meters, and is equipped with a complete set of testing equipment such as tensile testing machines, bending testing machines, and galvanized testing ensure that the products meet domestic and international relevant quality and standard requirements.
Our company has passed the ISO 9001 quality management system, ISO 14001 environmental management system and ISO 45001 occupational health and safety management system three international standard certifications, indicating that the company's comprehensive management capabilities in the fields of quality, environment and occupational health and safety have reached international standards.
